CAD Drafting and
Detailing QC Process

Drafting Quality

Three-step quality check process

Quality check

at important milestones during the project and
before submission.

Separate checklists

Separate checklists
maintained for each client.
These checklists evolve.

As they evolve, we add more items to our standardized templates and libraries, which in turn increases our efficiency.

We also sometimes suggest design elements or ideas based on the project manager’s experience.

Use of advanced plug-ins/software to achieve best output</
