Revit Millwork Detailing Coordinated first, fabricated properly.

Holding the coordinated position of everything.

Structure, services, ceilings, partitions and finishes, with the millwork having to fit what is already agreed.

Carrying scheduling and specification data.

Which is why a millwork item that exists in the model correctly is easier to specify, count and procure.

Setting the reference the design team reviews against.

On these projects a submittal is read alongside the model, not instead of it.

Millwork detailing coordinated against the project model,

so the item fits the space that has actually been agreed rather than the space the elevation showed.

Clash and clearance checking

where millwork meets other trades, before the drawing is issued.

Documentation to the level of development the project requires,

agreed at scoping rather than assumed.

Fabrication documentation produced properly,

which usually means a fabrication set derived alongside rather than inside the model. Where that is the right approach, we say so.

It is not a fabrication environment.

Design-side content supports coordination, scheduling and specification. Treating it as a fabrication instruction is a well-known way to build the wrong thing accurately.

A family is not a shop drawing.

Where a project needs both, which deliverable serves which purpose is stated clearly rather than left to assumption.

Content and family creation is separate work.

It sits under BIM and Revit millwork content rather than here.

Send a set from Revit →

Fabrication attempted from design-side content.

The most expensive failure, because the geometry looks right and the build information is not there.

Level of development assumed.

Content built heavier than needed slows every model it enters. Built lighter than assumed, it fails at coordination.

Millwork detailed without reference to the coordinated model.

Then found to conflict with services or structure that were agreed months earlier.

One deliverable expected to do two jobs.

A model that is meant to coordinate and fabricate usually does neither well.
