InsideOut Buildings Ltd
Case study

CAD Drafting for Garden Buildings

About InsideOut Buildings Ltd.

Gordon Smith RIBA and Lynn Fotheringham started the market-leading garden office company InsideOut Buildings (later rebranded as Garden Room Hub).

They have spent many years designing and building top-of-the-range garden buildings, from the Isle of Islay to the edge of Chichester harbour. They design and build garden offices, garden rooms and garden studios.

InsideOut Buildings Ltd
Project requirements

Project Requirements

  • Garden building projects where drawings had to be converted to AutoCAD.

  • The residential garden projects varied in size, from 500 sq. ft. to 1500 sq. ft. The construction plan set included floor plans, elevations and cross sections.
  • Doors and windows and elevations designs to be achieved as per client specifications. They were very particular with cladding details.

  • Client’s CAD standards and specifications were achieved.

Business advisor

Project Challenges

  • The average timeline for each project was only 24 hours, irrespective of time zone difference.

Blue bird

Maximum Value. Achieved

We successfully completed more than 6 projects for this client:

  • Kennedy Office

  • Roper

  • Collins

  • Smith

  • Pamplin

  • Fairclough
