Isaac Cotton
Case study

CAD Drafting and Conversions for Residences

About Isaac Cotton

Issac Cotton is an architect based in the US. He has rich experience in designing residences, stone work and column details.

The client approached BluEnt for CAD drafting assistance.

Isaac Cotton
Project requirements

Project Requirements

  • The scope of work was to draft construction drawings and details of residences, stonework and column details.

Project Challenges

Project Challenges

  • We had to correlate the plans and draft the elevations, sections and details as required.

  • The timeline was very short and strict.

Blue bird

Maximum Value. Achieved.

The client’s CAD standards and specifications were achieved.

We have successfully completed more than 3 projects for this client:

  • Issac Cotton Residence
  • Faulkner Residence
  • Stonework project – column and stonework details
