Case study

2D Drafting and CAD Conversions for Architectural and Structural Project

About PrograF/X Design

PrograF/X Design is a private company based out of Calgary, Canada. They provide architectural and AutoCAD drafting services.

Prograf/x Design
Project requirements

Project Requirements

PrograF/X is a CAD vendor for Birchwood, Eagle Copters and other architectural companies. Their different project types include developing/drafting brochures, showhomes, custom specific projects, individual homes, aircraft-electrical drawings and conversion of structural drawings.

Project Challenges
  • Projects were of different types, starting from brochures, individual homes, structural drawings, custom specific projects, sunrooms, etc. Every project type had its own specifications and guidelines to be followed and drafted accordingly.

  • Most of the drawings in the set were dependant and sequential. Hence, assigning more than one architect on a single drawing was challenging.

  • Volume of work was large and the project delivery timeline was very short.

Business advisor

The BluEnt Approach

  • Project submissions and deliverables within project timeline included redlines/markups and learning the CAD and design standards of the client.

  • Weekly meetings to review the progress of the projects were scheduled.

  • BluEnt had a fixed team of 7 people for PrograF/X.

Blue bird

Maximum Value. Achieved.

BluEnt believes in exceptional, timely services for all our clients. We leave no stone unturned for them.

We successfully delivered 2D drafting and CAD conversions for PrograF/X.
