Assembly shop drawings are majorly used for representing the craftwork consisting of multiple components. But before we go ahead and scrutinize further, let’s understand other fundamental parts to bring clarity on this topic.

What Are Shop Drawings?

According to Wikipedia, “A shop drawing is a drawing or set of drawings produced by the contractor, supplier, manufacturer, subcontractor, or fabricator. Shop drawings are typically required for prefabricated components”.

Shop drawings are a detailed presentation of construction and fabrication process which clearly talks about design, shape, structure size, material, and assembly of the items as well as the installation of the unit.

Now let’s move on to millwork shop drawings

What Are Millwork Shop Drawings?

Majority of high-end projects in both commercial and residential industry are using prefabricated wood construction for their interior designing purposes. In this competitive architectural construction environment, the millwork detailing service sector helps on fabricating and installing custom designed cabinets, architectural components, casework, and decorative items.

Millwork drafters and designers are producing the key plans, elevations, floor plans, section details, hardware schedules and finish for every kind of millwork structure.

What Are Assembly Shop Drawings?

Assembly shop drawings have a purpose of assembling the items together through visual information. These drawings involve:

  • Orthogonal sections, plans, and elevations explaining the assembling process.
  • 3-Dimensional View – Showing the final assembled product.
  • Exploded View – Explaining the connection between a variety of components and how they come together with each other.

Some millwork projects require showing the assembly shop drawings for the parts such as furniture, whereas some demand the assembly of the complex components of a building or may require showing a relation between the number of items with intricate details.

What Type of Details Assembly Shop Drawings Usually Involve?

Assembly drawings generally include instructions based on the complexity of the product and the requirements of the client. It may also include reference numbers, list of the components, references back to the details or shop drawings that lead the fabrication purpose ahead. However, millwork designers and architects need to be very careful that they are not repeating the similar information or detailing of the assembly shop drawings. If the similar information is duplicated, this might cause contradictions and confusions in the client’s head. It also involves notations, dimensions, and symbols. Every detail provided in the assembly shop drawing should stick to the industry standards as well.

Assembly Shop Drawings Have the Following Types:

  • General assembly shop drawings – involves overall components.
  • Outline assembly shop drawings – covering the exteriors of the assembled work.
  • Diagrammatic assembly shop drawings – involving symbols to represent the assembly.
  • Sub-assembly or Unit assembly shop drawings – detailed assembly of a part or a unit.
  • Fitted assembly shop drawings – final assembly.
  • Exploded assembly shop drawings – showcasing the relationship of different separate parts.

Assembly drawings can get complicated when multiple details are required. That’s why designers should prepare drawings which reflect the desired details such as assembling and convey the drawings’ purpose right.

Designers usually differentiate the thickness of lines to get clarity of certain parts of the complete work.

What Are Fabrication Drawings?

Fabrication drawings are detail drawings generally including material and part list for the purpose of identifying the type of materials used in fabrication.

Some of the fabrication drawings are also detailed as assembly drawings where multiple items are brought together as a fabrication.

These drawings also have the details related to the welding using the standard symbolic representation.

Conclusion

All millwork projects might not require every type of drawing mentioned above but the projects which have a lot of complex information. To avoid future risks and monetary loss, stakeholders prefer to incorporate detailed fabrication and assembly shop drawings.
