CAD Drafting for Design Development Drawings Set

About SRM Architects

The company was established as Snider Reichard March in 1961 and changed its name to SRM Architects Incorporated in 2006. SRM is committed to give their clients the confidence to produce quality buildings. The firm has received many awards for building excellence, merit, creative design options, and outstanding site development. They specialize in office, multi-residential and multi-use buildings and have experience with new construction, additions and adaptive re-use.

See our recent projects for more inspiration

SRM Architects
Project requirements

Project Brief

The Project Pinebush campus consists of two building blocks; the first block is Flex building block and second is Technical building block. The Technical building block with a gross area of 49,350 sq.ft. was in design phase and the building structure consisted of ground, second and third floor. The client was looking for a partner who could support them with design from initial concept plans and CAD drafting.

Project Challenges

Project Highlights

  • Design support (from initial concept plans) and CAD drafting for Pinebush Campus -Technical building block.

  • Correlated the plans and drafted the sectional elevations and details as per the building design.

  • Details of the drawings (scale, dimensions, formatting, standards, text etc.) had to be strictly based on the client’s instructions.

  • An issue-tracking template for project queries on day-to-day basis for easy understanding and coordination was maintained.
